Description
This would be best budget laser cutter, not only for home use but also for your business ,it is also be a best laser engraver and cutter in diode laser Engraving machine flied. 10W output free shipping with Fast dealivry, can be engraved on wood,metal,glass,leather,stone,mdf,and other metarials very fast
| Product Parameters | |
| Model Name | A10/S10/X7 Pro Diode Laser Engraver |
| Electric power | 50W |
| Input Voltage | AC100-240V |
| Output Voltage | DC12V, 5A |
| Optical power | 10-11W |
| Laser wavelength | 455±5nm |
| Engraving Speed | 11000mm/min |
| Compressed spot | YES |
| Engraving accuracy | 0.01mm |
| Slntering temperature | 1200℃ |
| Height adjustment | adjustment knob |
| Engraving size | 410*400mm |
| Support Extension | YES(850*440mm) |
| Support Offline work | YES |
| Data transmission Type | USB connection |
| Focusing Type | fixed focus laser, no focusing |
| Operating software | Laser GRBL,Lightburn |
| Input format | NC, BMP, JPG, PNG, DXF, etc |
| Certification | CE FCC Rosh FDA IEC-60825 |
| Marking effect | ✮✮✮✮✮ |
| Cutting effect | ✮✮✮✮✮ |
Main Features:
1. The new filter panoramic coated glass eye protection design:The innovative use of coated filter glass ensures better visual permeability, The internal movement track can be clearly seen when engraving. It can effectively filter the laser, prevent eye burns, and eliminate the hidden danger of easy burning of arcylic. filtering 97% of the ultraviolet light, you and the people around you do not need to wear goggles, you can also watch laser engraving. Reduce the cost of your goggles and the inconvenience of wearing goggles.
2. Solid and easy installation structure design: The all-aluminum alloy anodized structure design makes the machine more durable, and improves the accuracy of engraving. The entire structure has been designed for quick assembly, and the assembly can generally be completed within 10-20 minutes.
3. Upgraded high-performance fixed-focus laser: no need to adjust the focus before engraving; The focal spot area of the new laser is only 1/3 of the spot area of other ordinary lasers, new laser combine precision engraving and high energy cutting at the same time. The laser power of the fixed-focus laser is more stable than the zoom laser.The laser sintering temperature is up to 1200℃
4. Wide compatibility:The machine can be compatible with various mature engraving software, such as LaserGRBL, LightBurn, support Win XP / Win 7 / Win 8 / Win 10 / Win 11, and also support MAC system (LightBurn), engraving file format supports NC, BMP, JPG, PNG, DXF etc.
5. Precise scale lines axis: There are precise scale lines on the X-axis and Y-axis to facilitate quick length measurement. 410x400mm large area engraving interval can meet your various engraving needs.6. Upgraded dual compression spot coupling technology: ultra-fine laser focus area is reduced to 0.08*0.08mm, high-density laser can easily cut 20mm thick wood, 15mm thick black acrylic; can directly engrave mirror stainless steel metal, ceramics, glass, and engraving &The cutting speed is 40% higher than the ordinary model, which can be comparable to the effect of the 150W CO₂ laser engraving machine.
6. Integral screw rod: The machine uses an integrated screw rod instead of a combined coupling. The stepping motor and the screw rod are integrated, which makes the movement of the laser more precise and the coupling more durable.
7. New laser with knob: It is more convenient and quick to adjust the height of the laser.
8. Support offline engraving: A10 /S10/X7 PRO configures the terminal control panel, supports offline engraving, you can carry out engraving work anytime and anywhere without being restricted by the computer.
9.Emergency stop button: In the event of an unexpected situation, stop the machine at any time to make the engraving safer
10.Stopper: Yes ，Reset switch: Yes
11.Packing List
| Packing List | |||
| Item | Quantity(pcs) | Item | Quantity(pcs) |
| Support beam | 2 | Control box | 1 |
| Y-axis left slide rail | 1 | Y-axis right slide rail | 1 |
| Display screen | 1 | Lasr head | 1 |
| Connecting plate | 1 | Foot bracket | 3 |
| Power cable | 1 | Power Adapter | 1 |
| X-axis rail | 1 | Synchronous belt | 1 |
| Product Manual | 1 | Metal mat board | 1 |
| Fixed focus film | 1 | Mounting screws | 1 |
| Acrylic sheet | 3 | Wood chips | 3 |
| HDMI cable | 1 | USB card and card reader | 1 |
| USB cable | 1 | Dust-free cloth | 1 |
| Brush | 1 | Wire tie | 1 |
| Toolkit | 1 | ||
12.Expandable engraving size: modular design of the body mechanism, only need to replace the frame components, you can get 410*850mm super large engraving size
